CUT-i Series IGBT Inverter Air Plasma Cutter

CUT-100E




Product description:
# SMT Surface mount design,with advanced craft.
# With good protection of under voltage,over voltage and over current,it makes the machine safe and reliable.
# Exact digtal current display, it makes the machine be easy operated.
# Advanced Imported IGBT inverter technology,  high efficiency and energy saving.
# High frequency and high pressure arc striking,100% arc starting.
# Advanced air flow control systems,it has a save of 30% air compare
   to traditional machine,which prolongs the using life of air compressor.
# With self-lock working mode,it reduces the working intensity greatly.
# With tri-proof design,it ensures working stable and reliable
   when in kinds of adverse circumstances.


Model

CUT-101

Input power voltage (V)

380V±10

Frequency (HZ)

1~50Hz/60Hz

Rated input current (A)

16.9

No-load voltage (V)

360V

Current adjusting range (A)

40-100A

Rated input capacity (KVA)

16.9KVA

Duty cycle (%)

60

Working gas pressure(Mpa)

0.5-0.7

Case protection degree

IP21

Arc starting

Non Touch

Max.cutting thickness

<35mm

Weight (kg)

15

Overall dimension (mm)

460*220*365
